Quickly Convert Embedded Systems & Legacy RTOS source to Linux, Windows using the K.I.S.S. principle

Click here for Source to Source Conversion Home Page

Micro-Processor Services, Inc.
Tel. 631 499 4461
Contact us

Converting Legacy Mainframe & Embedded Applications to C, C++, CPP, C#, CS, JAVA, VB, Structured Text (ST), .NET

FEATURES

  • Simple to use, automated process
  • Translation of PowerPC fragments
  • Translation of INCLUDE or COPY files
  • Translation of PowerPC directives
  • Support for card format input
  • Extensive error checking diagnostics
  • Accurate translation
  • Run time interface
  • Easy to install
  • Compatible with many C and ANSI C compilers
  • Translates include files on the fly
  • Moves nested procedures
  • Completes unqualified structure members
  • Flags PowerPC syntax errors in listing file
  • Outputs ANSI C or K&R C
  • Generates C translation files with comments logically placed
  • Includes skeletons in C of runtime support functions
  • Provides a list of implicitly declared variables in each module
  • Has a by-pass capability that allows translation even with syntax errors in the input file
  • Converts PowerPC programs to C so you can move your program to other processors
  • Translation may be done in an editor environment with error message capability using "Brief" or any editor that is supported
  • Flags syntax errors and generates listing file with levels for include files
  • WIN32 protected mode operation allows translation of very large source files (more then to 500,000 lines per file)
  • KEYWORDS

    ASM, ASSEMBLY, Power,PowerPc ,ibm, MOTOROLA, PPC2C, ASSEMBLER,ASSEMBLER

    REFERENCES

    Macro Assemble Reference Manual by Motorola

    M6805 Microcomputer/microcontroler User's Manual By Motorola

    LINKS

    Why Convert from ASM to C?


    CONTACT

    Micro-Processor Services, Inc.
    Tel. 631 499 4461
    Fax. 631 499 4727
    Contact us

    PPC2C
    IBM, Motorola
    PowerPC assembly to "C" Translator, Converter:
    Reverse Engineering For Assembly Source Code


    The PPC2C® translator is a Microsoft Windows program that translates Motorola,IBM PowerPC (68000, 68010, 68020, 68030, 68040) programs to "C". The translation process is a turn key process with minimal user intervention. The translator output is ANSI C or K&R C code that is ready to be tested with the target compiler. Simply run your PowerPC code through the translator and start debugging C code with your target compiler.

    GENERAL DESCRIPTION

    The PPC2C® translator is a software tool that will convert existing Power, PowerPC, Power 601, Power 603 assembly programs to "C". The powerful PPC2C® translator accepts PowerPC programs, checks their syntax and outputs C code. The comments are moved transparently from the source file to the target file. Any built-in functions for math, string manipulation and I/O in PowerPC are converted to calls to external procedures (see sample translation) .

    The PPC2C® translator contains a syntax analyzer, a PowerPC to tertiary converter, and a tertiary to "C converter. The syntax analyzer scans the PowerPC input file for syntactic errors and generates a listing file of the PowerPC program. Any syntactic errors will be flagged with detailed English messages in the listing file. If no errors are encountered, the PowerPC input file is converted to tertiary language. Then the tertiary file is checked and, if no errors are detected, it is converted to "C". A command line control is provided to allow translation with errors in the source file. This is helpful when translating code fragments that are not complete programs.

    The translation of the PowerPC source language into an intermediate tertiary language ensures the logical equivalence between the source and target languages. This sophisticated tertiary language, which is common to our entire family of translators, allows complex mapping from source language to the target. The tertiary language is automatically converted to "C" while maintaining the logical equivalence between the output "C" program and the input PowerPC program.

    The "C" output file will be generated in

    1. Compact and portable K&R C
    2. Standard ANSI C code

    as selected by a command line option.

    PowerPC DIRECTIVES: END INCLUDE MASK2 OFFSET ORG SECTION EQU FEQU REG SET COMLINE DC DCB FAIL FOPT FORMAT NOFORMAT LIST NOLIST NOL LLEN NOOBJ OPT PAGE NOPAGE SPC TTL IDNT XDEF XREF

    PowerPC RESERVED WORDS:

    A AD AO AOD ABCD ABS ABSD ABSO ABSOD ADD ADDO ADDD ADDOD ADDC ADDCO ADDCD ADDCOD ADDE ADDEO ADDED ADDEOD ADDI ADDIC ADDICD ADDIS ADDZE ADDZED ADDZEO ADDZEOD ADDME ADDMED ADDMEO ADDMEOD AE AED AEO AEOD AI AID AD AME AMED AMEO AMEOD AND ANDD ANDC ANDCD ANDI ANDID ANDIS ANDISD ANDIL ANDILD ANDISU ANDISUD B BA BL BLA BC BCA BCC BCCL BCL BCLA BCCTR BCCTRL BCLR BCLRL BCR BCRL CAX CAXD CAXO CAXOD CLCS CLF CLI CMP CMPI CMPL CMPLI CNTLZ CNTLZd CNTLZD CNTLZDD CNTLZW CNTLZWD CRAND CRANDC CREQV CRNAND CRNOR CROR CRORC CRXOR DCBF DCBI DCBST DCBT DCBTST DCBZ DCLST DIV DIVd DIVO DIVOd DIVD DIVDd DIVDO DIVDOd DIVDU DIVDUd DIVDUO DIVDUOd DIVS DIVSd DIVSO DIVSOd DIVW DIVWd DIVWO DIVWOd DIVWU DIVWUd DIVWUO DIVWUOd DOZ DOZD DOZO DOZOD DOZI ECIWX ECOWX EIEIO EXTSW EXTSWD EQV EQVD EXTSB EXTSBD EXTSH EXTSHD EXTS EXTSD FA FAD FADDS FADDSD FABS FABSD FADD FADDD FCFID FCFIDD FCMPO FCMPU FCIR FCIRD FCIRZ FCIRZD FCTID FCTIDD FCTIDZ FCTIDZD FCTIW FCTIWD FCTIWZ FCTIWZD FD FDD FDIV FDIVD FDIVS FDIVSD FM FMD FMA FMAD FMADD FMADDD FMADDS FMADDSD FMR FMRD FMS FMSD FMSUB FMSUBD FMSUBS FMSUBSD FNABS FNABSD FNEG FNEGD FNMA FNMAD FNMADD FNMADDD FNMADDS FNMADDSD FNMS FNMSD FNMSUB FNMSUBD FNMSUBS FNMSUBSD FRES FRESD FRSP FRSPD FRSQRTE FRSQRTED FS FSD FSEL FSELD FSQRT FSQRTD FSQRTS FSQRTSD FSUB FSUBD FSUBS FSUBSD ICS ICBI ISYNC LBZ LBZU LBZUX LBZX LD LDARX LDU LDUX LDX LFD LFDU LFDUX LFDX LFQ LFQU LFQUX LFQX LFS LFSU LFSUX LFSX LHA LHAU LHAUX LHAX LHBRX LHZ LHZU LHZUX LHZX> LM LMW LQ LSCBX LSCBXD LSI LSWI LSWX LSX LU LUX LWA LWARX LWAUX LWAX LWBRX LWZ LWZU LWZUX LWZX LX MASKG MASKGD MASKIR MASKIRD MCRF MCRFS MCRXR MFCR MFFS MFFSD MFMSR MFOCRF MFSPR MFSR MFSRI MFSRIN MTCRF MTFSB0 MTFSB0D MTFSB1 MTFSB1D MTFSF MTFSFD MTFSFI MTFSFID MTOCRF MTMSR MTSPR MTSR MTSRI MTSRIN MUL MULD MULO MULOD MULI MULS MULSD MULSO MULSOD MULHD MULHDD MULHDU MULHDUD MULHW MULHWD MULHWU MULHWUD MULLD MULLDD MULLDO MULLDOD MULLI MULLW MULLWD MULLWO MULLWOD NABS NABSD NABSO NABSOD NAND NANDD NEG NEGD NEGO NEGOD NOR NORD OR ORD ORC ORCD ORI ORIL ORIU ORID ORIS RAC RACD RFI RFID RFSVC RLDCL RLDCLD RLDCR RLDCRD RLDIC RLDICD RLDICL RLDICLD RLDICR RLDICRD RLDIMI RLDIMID RLMI RLMID RLWIMI RLWIMID RLWINM RLWINMD RLWNM RLWNMD RRIB RRIBD SC SCV SI SID SLD SLDD SLE SLED SLEQ SLEQD SLIQ SLIQD SLLIQ SLLIQD SLLQ SLLQD SLQ SLQD SLW SLWD SRAD SRADD SRADI SRADID SRAIQ SRAIQD SRAQ SRAQD SRAW SRAWD SRAWI SRAWID SRD SRDD SRE SRED SREA SREAD SREQ SREQD SRIQ SRIQD SRLIO SRLIOD SRLQ SRLQD SRQ SRQD SRW SRWD STB STBU STBUX STBX STD STDCX STDCXD STDU STDUX STDX STFD STFDU STFDUX STFDX STFIWX STFQ STFQU STFQUX STFQX STFS STFSU STFSUX STFSX STH STHBRX STHU STHUX STHX STMW STQ STSWI STSWX STW STWBRX STWCX STWCXD STWU STWUX STWX SUBF SUBFD SUBFO SUBFOD SUBFC SUBFCD SUBFCO SUBFCOD SUBFE SUBFED SUBFEO SUBFEOD SUBFIC SUBFME SUBFMED SUBFMEO SUBFMEOD SUBFZE SUBFZED SUBFZEO SUBFZEOD SVC SVCL SYNC TD TDI TLBIE TLBLD TLBLI TLBSYNC TW TWI XOR XORD XORI XORIL XORIU XORIS

    Registers
    DR0 DR1 DR2 DR3 DR4 DR5 DR6 DR7
    AR0 AR1 AR2 AR3 AR4 AR5 AR6 AR7
    RR0 RR1 RR2 RR3 RR4 RR5 RR6 RR7 RR8 RR9 RR10 RR11 RR12 RR13 RR14 RR15
    PC SR USP CCR SSP

    TECHNICAL INFORMATION

    CPU SUPPORTED: MOTOROLA, IBM, etc.

    HOSTS SUPPORTED: The translators run under all Microsoft Windows platforms. Porting of the translator to other hosts is available.

    TRANSLATION METHOD: Double conversion from PowerPC to tertiary and then from tertiary to "C".

    TRANSLATION CAPACITY: WIN32 version can translate more then 500,000 lines per file.

    TRANSLATOR RUN TIME SUPPORT: Skeletons in "C" of the run time support function are available with the translator.

    SOFTWARE FORMAT AND MEDIA: CD for Windows.

    DOCUMENTATION: User's Guide

    COPY PROTECTION: Includes a USB security lock

    SUPPORT: Includes 30 days free telephone or e-mail technical support. For updates, monthly support must be purchased.

    WEIGHT: 2 pounds

    ORDER: PPC2C
