FEATURES

  • Simple to use, automated process
  • Translation of ASM68K fragments
  • Translation of INCLUDE or COPY files
  • Translation of ASM68K directives
  • Support for card format input
  • Extensive error checking diagnostics
  • Accurate translation
  • Run time interface
  • Easy to install
  • Compatible with many C and ANSI C compilers
  • Translates include files on the fly
  • Moves nested procedures
  • Completes unqualified structure members
  • Flags ASM68K syntax errors in listing file
  • Outputs ANSI C or K&R C
  • Generates C translation files with comments logically placed
  • Includes skeletons in C of runtime support functions
  • Provides a list of implicitly declared variables in each module
  • Has a by-pass capability that allows translation even with syntax errors in the input file
  • Converts ASM68K programs to C so you can move your program to other processors
  • Translation may be done in an editor environment with error message capability using "Brief" or any editor that is supported
  • Flags syntax errors and generates listing file with levels for include files
  • WIN32 protected mode operation allows translation of very large source files (more then to 500,000 lines per file)
  • KEYWORDS

    ASM, ASSEMBLY, ASM68000, ASM68010, ASM68020, ASM68030, ASM68040, MOTOROLA, ASM68K2C, ASSEMBLER,ASSEMBLER

    REFERENCES

    Macro Assemble Reference Manual by Motorola

    M68000 Microcomputer/microcontroler User's Manual By Motorola

    LINKS

    Why Convert from ASM to C?

    Micro Controller FAQ

    Disassembling FAQ

    CONTACT

    Micro-Processor Services, Inc.
    Tel. 631 499 4461
    Fax. 631 499 4727
    Contact us

    ASM68K2C
    Motorola ASM 68K to "C" Translator, Converter:
    Reverse Engineering For Assembly Source Code


    The ASM68K2C® translator is a Microsoft Windows program that translates Motorola ASM68K (68000, 68010, 68020, 68030, 68040) programs to "C". The translation process is a turn key process with minimal user intervention. The translator output is ANSI C or K&R C code that is ready to be tested with the target compiler. Simply run your ASM68K code through the translator and start debugging C code with your target compiler.

    GENERAL DESCRIPTION

    The ASM68K2C® translator is a software tool that will convert existing ASM68K programs to "C". The powerful ASM68K2C® translator accepts ASM68K programs, checks their syntax and outputs C code. The comments are move transparently from the source file to the target file. Any built-in functions for math, string manipulation and I/O in ASM68K are converted to calls to external procedures (Get free sample translation) .

    The ASM68K2C® translator contains a syntax analyzer, an ASM68K to tertiary converter, and a tertiary to "C converter. The syntax analyzer scans the ASM68K input file for syntactic errors and generates a listing file of the ASM68K program. Any syntactic errors will be flagged with detailed English messages in the listing file. If no errors are encountered, the ASM68K input file is converted to tertiary language. Then the tertiary file is checked and, if no errors are detected, it is converted to "C". A command line control is provided to allow translation with errors in the source file. This is helpful when translating code fragments that are not complete programs.

    The translation of the ASM68K source language into an intermediate tertiary language ensures the logical equivalence between the source and target languages. This sophisticated tertiary language, which is common to our entire family of translators, allows complex mapping from source language to the target. The tertiary language is automatically converted to "C" while maintaining the logical equivalence between the output "C" program and the input ASM68K program.

    The "C" output file will be generated in

    1. Compact and portable K&R C
    2. Standard ANSI C code
       as selected by a command line option.

    Assemblers Supported:

    1. Motorola ASM68k assembler
    2. Motrorola HI-ASM assembler
    3. ASM_ONE assembler
    4. Hisoft Devpac assembler





    ASM68K DIRECTIVES: END INCLUDE MASK2 OFFSET ORG SECTION EQU FEQU REG SET COMLINE DC DCB FAIL FOPT FORMAT NOFORMAT LIST NOLIST NOL LLEN NOOBJ OPT PAGE NOPAGE SPC TTL IDNT XDEF XREF

    ASM68K RESERVED WORDS:

    ABCD ADD ADDA ADDI ADDQ ADDX AND ANDI ASL ASR BCC BCHG BCLR BFCHG BFCLR BFEXTS BFEXTU BFFFO BFINS BFSET BFTST BKPT BRA BSET BSR BTST CALLM CAS CAS2 CHK CHK2 CLR CMP CMPA CMPI CMP2 DBCC DIVS DIVU EOR EORI EXG EXT EXTB EXTW JMP JSR LEA LINK LSL LSR MOVE MOVEA MOVEC MOVEM MOVEP MOVEQ MOVES MULS MULU NBCD NEG NEGX NOP NOT OR ORI PACK PEA RESET ROL ROR ROXL ROXR RTD RTE RTM RTR RTS SCD SCC STOP SUB SUBA SUBI SUBQ SUBX SWAP TAS TCC TDIVS TDIVU TPCC TRAP TRAPV TST UNLK UNPK

    REGISTERS: D0 D1 D2 D3 D4 D5 D6 D7 A0 A1 A2 A3 A4 A5 A6 A7 USP SSP PC TS



    TECHNICAL INFORMATION

    CPU SUPPORTED: MOTOROLA 68010, 68020, 68030, 68040

    HOSTS SUPPORTED: The translators run under all Microsoft Windows platforms. Porting of the translator to other hosts is available.

    TRANSLATION METHOD: Double conversion from ASM68K to tertiary and then from tertiary to "C".

    TRANSLATION CAPACITY: WIN32 version can translate more then 500,000 lines per file.

    TRANSLATOR RUN TIME SUPPORT: Skeletons in "C" of the run time support function are available with the translator.

    SOFTWARE FORMAT AND MEDIA: CD for Windows..

    DOCUMENTATION: User's Guide

    COPY PROTECTION: Includes a USB security lock

    SUPPORT: Includes 30 days free telephone or e-mail technical support. For updates, monthly support must be purchased.

    WEIGHT: 2 pounds

    ORDER: ASM68K2C
