Quickly Convert Embedded Systems & Legacy RTOS source to Linux, Windows using the K.I.S.S. principle

Click here for Source to Source Conversion Home Page

Micro-Processor Services, Inc.
Tel. 561 302 3276
Contact us

Source to Source Compilers for Converting Legacy Mainframe & Embedded Applications to C, C++, CPP, C#, CS, JAVA, VB, NinjaScript, Structured Text (ST), .NET

Software Product Box Image


  • Simple to use, automated process
  • Translation of PL/I fragments
  • Translation of INCLUDE or COPY files
  • Translation of PL/I directives
  • Support for card format input
  • Extensive error checking diagnostics
  • Accurate translation
  • Run time interface
  • Easy to install
  • Compatible with many PL/I compilers
  • Translates include files on the fly
  • Moves nested procedures
  • Completes unqualified structure members
  • recognizes EXEC, END-EXEC pair for DB2 and SQL.
  • Flags PL/I syntax errors in listing file
  • Outputs ANSI C or K&R C
  • Generates C translation files with comments logically placed
  • Includes skeletons in C of runtime support functions
  • Provides a list of implicitly declared variables in each module
  • Has a by-pass capability that allows translation even with syntax errors in the input file
  • Converts PL/I programs to C so you can move your program to other processors
  • Translation may be done in an editor environment with error message capability using "Brief" or any editor that is supported
  • Flags syntax errors and generates listing file with levels for include files
  • WIN32 protected mode operation allows translation of very large source files (more then to 500,000 lines per file)



    A Guide to PL/1 Pollack & Sterling
    PL/I Structured Programming Joan K.Hughes
    Structured Pl/O Plus PL/1 Kennedy& Solomon
    Programming Language PL/I subset standard ANSI X3.74-1987 PL/I
    Programming language PL/I full set standard ANSI X3.53-1976 PL/I
    DB2 The complete guide to implementation and Use Jeff D. Vowell, Jr.
    AS400 PL/I User Guide and reference IBM
    Power Programming With PL/I John W. Winters, PH.D.


    Micro-Processor Services
    Contact us

    PL/I, PL1 to "C" Translator, Converter, Compiler.

    The PL1C® translator is a family of Microsoft Windows cross compiler programming tools that accepts many PL/I source code dialects and translates them to C. The translation process is a simple turn key process with minimal user intervention. The translator output is ANSI C or K&R C code that is ready to be tested with the target compiler. Simply run your PL/I code through the translator and start debugging C code with your target compiler

    Other PL/I translators : PL1CPP ,PL1CS ,PL1JAVA ,


    The Pl1C® family of software translator tools convert existing PL/I programs to C. The powerful dual conversion PL1C® translators accept PL/I programs in numerous dialects, check their syntax, analyze the syntax tree and generate C source code. Comments are moved transparently from the source file to the target file. Any built-in functions for math, string manipulation, and I/O in PL/I are converted to calls to external procedure. (to see PL/I to C sample translation(PDF)) The translator family currently supports the following PL/I dialects: For other dialects or custom translation, please contact us for a price quote.

    Dialect type 1: PL/C Cornell University PL/I
    Dialect type 2: PL/I for IBM series 1
    Dialect type 3: PL/I-D IBM PL/I subset compiler that runs under DOS
    Dialect type 4: PL/I-F IBM PL/I full language compiler runs under DOS
    Dialect type 5: DRI PL/I-D DIGITAL RESEARCH PL/I general purpose subset
    Dialect type 6: IBM optimizer PL/I compiler runs under DOS
    Dialect type 7: IBM optimizer PL/I - OS
    Dialect type 8: ANSI X3.7-1987 PL/I general purpose subset
    Dialect type 9: ANSI x3.53-1976, ISO 6160-1979 PL/I
    Dialect type 10: Prime PL/I
    Dialect type 11: Stratus PL/I
    Dialect type 12: Data General PL/I
    Dialect type 13: VAX PL/I
    Dialect type 14: IBM visual Age PL/I

    ORDER: PL1C type x ( select one from above)

    The PL1C® translators contain a syntax analyzer, a PL/I to tertiary converter, and a tertiary to C converter. The syntax analyzer scans the PL/I input file for syntactic errors and generates a listing file of the PL/I program. Any syntactic errors will be flagged with detailed English messages in the listing file. If no errors are encountered, then the PL/I input file is converted to tertiary language.

    The transfer of the PL/I source language into an intermediate tertiary language ensures the logical equivalence between the source and target languages. This tertiary language is common to the entire family of our translators. The tertiary language is automatically converted to C while maintaining the logical equivalence between the output C program and the input PL/I program.


    Note: The number in the parentheses indicates the number of formats supported for this

    allocate statement
    assignment statement
    call statement
    close statement
    delete statement
    free statement
    get statement
    leave statement
    goto statement
    locate statement
    null statement
    open statement
    read statement
    put statement
    read statement
    return statement
    revert statement
    rewrite statement
    signal statement
    stop statement
    write statement

    * This statement is not translated. It is passed
    through as a comment.


    aligned area binary bit character complex decimal entry file fixed float format label member non varying offset picture pointer precision real structure union unaligned varying


      WEIGHT: 2 pounds

    ORDER: PL1C type xx ( select one from above)
